| OS |
Android 12 |
| CPU |
Quad-Core ARM Cortex-A35 |
| GPU |
Mali-G31 MP2 |
| Memory |
2GB |
| Storage |
16GB eMMC |
| NFC / RFID |
Opt.1: 13.56MHz Opt.2: 13.56MHz & 125KHz (Ver. H) Opt.3: Apple wallet compatible (Ver. O) |
| Video decoder |
H.265,H.264,VC-1, MPEG-1/2/4, VP8 |
| Image codecs |
JPEG/PNG (Max. 1920 x 1080) |
| Display |
| Size(inch) |
3.6“, on-cell touch |
| Display Resolution |
480 x 480 |
| Color |
16.7M |
| Viewing angle (H/V) |
170/170 degree |
| Brightness |
350 nits |
| Orientation display |
Landscape / Portrait |
| I/O Interface ( External ) |
|
| USB type C |
x1, Power-in |
| Micro USB |
x1, ADB function |
| LED light indicator |
x2, 256 color (1x front, 1x rear) |
| Power & Connectivity |
|
| RF communication |
WiFi 5 |
| Power input |
5V/2A |
| Mechanical |
|
| Dimension (WxDxH) (mm / inch) (Estimated) |
90 mm x 90 mm x 13mm (3.54”x 3.54” x 0.51”) |
| Net. Weight (Estimated) |
130g |
| Weight with packing (Estimated) |
180g |
| Mounting type |
Glass / Surface / Wall |
| Material |
PC |
| Environment |
|
| Operating Temperature(oC) |
0~40℃ |
| Storage Temperature (package included) (oC) |
-20℃ to 60℃ |
| Ambient Relative Humidity |
0 to 90% (non-condensing) |
| Certification & Safety |
|
| Certification |
CE/UKCA/FCC/IMDA/CB |
| Green |
RoHS / REACH |
| Warranty |
|
| Warranty Period |
1 year |
| Accessory |
|
| Screw |
Yes |
| Bracket |
Yes |
| Tape |
Yes |
| QSG |
Yes |
| Desktop stand |
|
