| OS |
Android 12 |
| Touch |
Yes, Multi touch |
| NFC/RFID(Optional) |
Std. Version (13.56MHz) |
| Opt. |
H Version, (Embedded Human-Interface-Device) (13.56M&125KHz) |
| Memory |
2GB LPDDR4 |
| Storage |
32GB eMMC |
| Video decoder |
H264 / H265,VC-1, MPEG-4, VP9 |
| Image codecs |
JPEG/BMP/GIF/PNG |
| Audio codecs |
MPEG/OGG/AAC |
| CPU |
ARM Quad-core Cortex-A55 up to 2.0GHz (64 bit) |
| PoE |
PoE+ (25W) |
| Bluetooth |
Yes, BLE Beacon (Optional) |
| Microphone |
2 (Noise Reduction & Auto Echo Cancellation) |
| ALS + Proximity sensor |
Yes |
| WatchDog |
Yes, Independent watchdog |
| Display |
|
| Size |
10.1" (85/85/85/85) |
| Resolution |
1920 x 1200(FHD) |
| Contrast |
1000:1 |
| Brightness |
430 nits |
| I/O Interface |
|
| Ethernet |
1 x RJ45 (10M/100M/1000M) |
| USB |
2 x USB2.0 type A/ 1 x USB3.0 type C (w/ ADB) |
| Analog Stereo out |
1 x 3.5mm stereo (MIC-in & Audio-out) |
| Expansion storage |
1 x Micro SDHC/SDXC slot |
| Speaker |
2W x 2 |
| Camera |
1 x 8M with HDR |
| Mechanical & Environment |
|
| Dimensions (WxDxH)(Without stand) |
242.9 x 173.4 x 20.5 mm |
| Mounting |
Glass / Surface / Recessed |
| Housing |
Plastic & Mg-Al Alloy |
| Environment |
Operating Temp. 0~50°C |
| Connectivity |
|
| WLAN |
WLAN 802.11B/G/N/AC (Optional) |
| Power |
|
| Input Voltage (V) : |
DC 12V |
